Jaltest 14.3 Released


Now covering 208 brands, 3994 models and 35,032 systems! In 14.3 Jaltest Soft provides 13,774 wiring diagrams and 8,069 technical information articles.

Jaltest Soft 14.3 – New Functions

Calendar and time are integrated in the main screen

The main connection screen includes the most relevant information about the connected system

New report closing process – “Stop diagnostics report” icon added

Example given after a system scan

New function to rotate wiring diagrams

New function “system display” allows the user to visualise the different inputs and outputs controlled by the system on an operational scheme

New design for the Glossary

ETM – New Diagnostic Functions

New easier and faster update process

New modules to check inductive wheel speed sensors and brake pad wear sensors

Module for wheel speed sensors used in ABS/EBS systems

Module for brake pad wear sensors

Jaltest 14.3 – New Diagnostic Functions

DAF Trucks

New functionality for systems on Euro 6 models (CF MX-11 E6, CF MX-13 E6, XF E6) Highlight functions:

  • PCI, Paccar Common‐Rail Injection
    • Throttle pedal calibration, acceleration test, turbocharger actuator
  • EAS‐3, Emission Aftertreatment System
    • AdBlue system purge, heaters activation
  • ECAS‐4 Electronic Control Air Suspension
    • Parameters copy
  • EBS 3, Electronic Braking System
  • SAC, Smart Air supply Control
    • Air dryer maintenance
  • EST‐52, Retarder
    • Components actuation
  • BBM, Body Builder Module
    • PTO parameters configuration

CF 65 IV, LF 45 IV & LF 55 IV, NOX data reset integrated in ECS‐DC4

IVECO Trucks

Coverage improvements in Euro 6 (Stralis Hi-Way, Hi-Road, Hi-Street and Trakker) Highlight functions:

  • Auxiliary heater, Eberspächer
  • CU, Climate unit
  • IVTM, Tyre pressure control
  • ACC, Adaptive Cruise Control
  • LDWS, Lane Departure Warning System
  • Iveconnect, Multimedia screen
  • UTP, Telematic Unit

MAN Trucks

Coverage improvement in Euro 6 (TGL Euro 6, TGM Euro 6, TGS Euro 6, TGX Euro 6)

Highlight functions:

  • EDC 17, Electronic Diesel Control, injectors calibration
  • DPF, differential pressure sensor reset
  • PTM, Powertrain Module, new actuations
  • Service PTM, additional maintenances

Mercedes Benz Trucks

Coverage improvement for Actros 4, Antos and Arocs.

Highlight functions:

  • ATA, Alarm system, Alarm record reset.
  • CPC, Common Powertrain Control, parameters configuration
  • CGW, Gateway, fuel and AdBlue tank volume configuration

Likewise the wiring diagrams of the main systems have been developed.

New diagnosis functions for Actros 2/3 (WDB930.0-934.3)

  • BS, Braking system, Steering angle sensor calibration (FDR).
  • INS, PTO configuration
  • GM, basic module, daylight configuration

Vehicle level learning process and parameters copy in NR Siemens, electronically controlled suspension system installed in Atego 9BM958.0 – OBD, Atego WDB970-976, NAB374.4 – OBD, Atego WDF375.1, NMB375.1 – OBD, Axor -C 9BM958.4 – OBD, Axor -C WDB940 – 944, NAB374.6

Nissan Trucks

Engine system for NT500 model has been developed, including parameters configuration, calibrations, components actuations.

Renault Trucks

In the main systems of Euro 6 models (engine, brakes, gearbox, exhaust gases after treatment system, compressed air processing) the basic diagnosis functions have been developed.

  • C Series V3 Euro 6
  • C Series V4 Euro 6
  • K Series V4 Euro 6
  • T Series V4 Euro 6

Scania Trucks

New Euro 6 models of series R, P and G have been developed with a high coverage for diagnosis and technical information.

Relevant functions for Euro 4 and 5 models have been developed.

Highlight functions:

  • EGR system reset, parameters restoration and speed limit modification in EMS PDE, P,R and G series
  • Parameters configuration in RET (retarder) P,R and G series

Volvo Trucks

In Euro 6 models main diagnosis functions have been developed:

  • FE V3 Euro 6
  • FE V4 Euro 6
  • FH V3 Euro 6
  • FH V4 Euro 6
  • FL V3 Euro 6
  • FL V4 Euro 6
  • FM V3 Euro 6
  • FM V4 Euro 6

Trailer systems

Better coverage in Haldex EB+ Gen 3: internal accelerometer calibration, system counters reset and more parameters configuration.


New technical information and wiring diagrams for the following brands:

  • Citroën
  • Dodge
  • Fiat

New diagnosis function highlights:

  • Mercedes Benz
    • DPF regeneration process while vehicle is moving, CR/EDC 16CP31 MB Sprinter
    • Learning process in gearbox EGS SSG for MB Sprinter
    • DPF regeneration CDID2, Electronic Diesel control
  • Ford
    • System purge ABS ISO9, Ford Series E & F
    • New system ABS HSCAN, Ford Series F
    • Injector coding and parameter configuration EEC5/ EDC CR Delphi, Ford Transit
  • GM
    • ECM L31, new engine system
    • ECM LH6, new engine system
    • Development of the system Aisin A465, Transmission Electronic Control Unit
    • Development of the 4HK1-TC (CAN), Electronic Diesel Control, Common Rail
  • Hino USA
    • System reset HABS Meritor Wabco
    • Development of DCU, Exhaust gas treatment system, including system reset and actuations of the main components
    • Development of the EDC J08E-TB, Electronic Diesel Control
  • Isuzu
    • Development of system 4HK1-TC
    • Development of system 6HK1-TC
  • Piaggio – New Brand!
    • Development of the main systems of Porter with engine BDT1M:
      • EPS Delphi, Steering controller,
      • ABS MK25, Anti-lock braking system
      • EDC 17 C08, Electronic Diesel control
  • Renault
    • Development of the system EDC ECCS ZD-K, Electronic diesel control, for Mascott DXi phase II models including DPF regeneration & injector coding
    • Development of the system Body Computer 3.7 for Master DCi


New brands:

  • Buhler Versatile, tractor models with Cummins engines
  • Challenger, tractor models with Caterpillar engines
  • Energreen, including ILF with John Deere engine
  • Frank Kleine, including SF10 with Volvo engine
  • Hürlimann, series XB, XL, XM, XS, XT models
  • JCB, Fastrac models
  • Laverda, including M Series models with Caterpillar engines
  • Ropa, Euro-Tiger series models

As well as new technical information in the following brands:

  • Case
  • Class
  • Deutz-Fahr
  • Fendt
  • John Deere
  • Lamborghini
  • Massey Ferguson
  • New Holland
  • Same

Asian market vehicles


Injector coding in engines N04C-TT, N04C-TV/UT, N04C-UY, A09C-TK, J08E-TB, N04C-TF & S05C-TB installed in vehicles of Series 300, 500 & Dutro.


Fuel pressure test 4HK1-TC and activations of the gearbox AISIN A465. New technical information, including the wiring diagram for ABS/ASR Hydraulic.


JDC 114A Adapter for Haldex EB+ Gen3
